Chapter 1: Product Introduction

IRQ assignments for this motherboard

A B C D E F G H

HD Audio Controller Shared – – – – – – –

XHCI Controller Shared – – – – – – –

SATA Controller Shared – – – – – – –

LAN Controller Shared – – – – – – –

PCIE x16_1

Shared – – – – – – –

PCIE x1_1 Shared – – – – – – –

PCIE x1_2 – – Shared – – – – –

M.2 Shared – – – – – – –

1.5.3 PCI Express 3.0 x1 slots

This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that

comply with the PCI Express specications.

1.5.4 PCI Express 3.0 x16 slot

This motherboard supports PCI Express x16 graphic cards that comply with the PCI Express

specications.
