E Controller LED, I2C, and Alarm Connector Quick Reference
This appendix provides a reference guide for Adaptec RAID controller activity LED connectors, I2C
connectors, and external alarm connectors.
Adaptec RAID 6405/6445 LED and I2C Connector Specication
ASR-6405 Kit2271100-R
ASR-6405 SGL2270000-R
ASR-6445 SGL2270200-R
• Adaptec RAID 6405/6445 Activity LED Header Connector: Molex 22-43-6030 or equivalent
• Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
22-55-2161 Pin
Number
DescriptionSignalJ2 Pin Number
2LED Anode+3.3V1
1LED CathodeACTIVITY CN0, LANE 02
4LED Anode+3.3V3
3LED CathodeACTIVITY CN0, LANE 14
6LED Anode+3.3V5
5LED CathodeACTIVITY CN0, LANE 26
8LED Anode+3.3V7
7LED CathodeACTIVITY CN0, LANE 38
• Adaptec RAID 6405/6445 Aggregate Activity LED Board Connector: Molex 22-28-4023 or equivalent
• Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
DescriptionSignalJ1 Pin Number
LED CathodeACTIVITY2
LED Anode+3.3V1
• Adaptec RAID 6405/6445 External Alarm Connector: Molex 22-28-4023 or equivalent
• Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
DescriptionSignalJ12 Pin Number
Open collector transistor~2kHz Square Wave2
—+3.3V1
• Adaptec RAID 6405/6445 I2C CN0 Board Connector: Molex 22-43-6030 or equivalent
• I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J4:
SignalJ4 Pin Number
I2C Clock, CN03
101Proprietary and Condential to PMC-Sierra, Inc., and for its customers.
Document No.: CDP-00310-01-A Rev. A, Issue
Serial Attached SCSI RAID Controllers Installation and User's Guide
