![Adaptec asr-5405 kit [104/116] Adaptec raid 6805e 6805e r5 led connector specification](/img/pdf.png)
Adaptec asr-5405 kit [104/116] Adaptec raid 6805e 6805e r5 led connector specification
![Adaptec asr-5405 kit [104/116] Adaptec raid 6805e 6805e r5 led connector specification](/views2/1163701/page104/bg68.png)
DescriptionSignalJ1 Pin Number
LED CathodeACTIVITY2
LED Anode+3.3V1
• Adaptec RAID 6405E External Alarm Connector: Molex 22-28-4023 or equivalent
• Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
DescriptionSignalJ12 Pin Number
Open collector transistor~2kHz Square Wave2
—+3.3V1
Adaptec RAID 6805E/6805E R5 LED Connector Specication
ASR-6805E Kit2271800-R
ASR-6805E SGL2270900-R
ASR-6805E R5 BULK2275600-R
• Adaptec RAID 6805E/6805E R5 Activity LED Header Connector: Molex 22-43-6030 or equivalent
• Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
22-55-2161 Pin
Number
DescriptionSignalJ2 Pin Number
2LED Anode+3.3V1
1LED CathodeACTIVITY CN0, LANE 02
4LED Anode+3.3V3
3LED CathodeACTIVITY CN0, LANE 14
6LED Anode+3.3V5
5LED CathodeACTIVITY CN0, LANE 26
8LED Anode+3.3V7
7LED CathodeACTIVITY CN0, LANE 38
10LED Anode+3.3V9
9LED CathodeACTIVITY CN1, LANE 010
12LED Anode+3.3V11
11LED CathodeACTIVITY CN1, LANE 112
14LED Anode+3.3V13
13LED CathodeACTIVITY CN1, LANE 214
16LED Anode+3.3V15
15LED CathodeACTIVITY CN1, LANE 316
• Adaptec RAID 6805E/6805E R5 Aggregate Activity LED Board Connector: Molex 22-28-4023 or
equivalent
• Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
104Proprietary and Condential to PMC-Sierra, Inc., and for its customers.
Document No.: CDP-00310-01-A Rev. A, Issue
Serial Attached SCSI RAID Controllers Installation and User's Guide
