10. Complete the VMware installation, following the on-screen instructions.
11. Remove the custom boot CD, then reboot your computer.
Installing with Citrix XenServer
Note: To install the Adaptec RAID controller driver with Citrix XenServer, you must
burn the XenServer driver iso image to a writeable CD (see Creating a Driver Disk on
page 52). You will be prompted to insert the XenServer driver CD twice. You need the
XenServer installation CD to complete this task. You must have administrator privilege
to install the driver image.
To install the Adaptec RAID controller driver while installing Citrix XenServer:
1. On the machine where you want to install the OS and RAID controller driver, insert the XenServer
installation CD, then restart your computer.
2. When prompted to add a driver, press F9.
3. Remove the XenServer installation CD and insert the driver CD.
4. When the driver update is complete, remove the driver CD and insert the XenServer installation CD.
5. Continue the XenServer installation, following the on-screen instructions.
6. When prompted to add a driver (at the end of the OS installation),remove the XenServer installation
CD and insert the driver CD.
7. Complete the XenServer installation, following the on-screen instructions.
8. Remove the driver CD, then reboot your computer.
