Adaptec RAID 7805/7805Q/71605/71605Q/71605E Alarm Connector
Specication
ASR-7805 SGL2274100-R
ASR-7805 Kit2274200-R
ASR-7805Q SGL2274300-R
ASR-71605 SGL2274400-R
ASR-71605E SGL2274500-R
ASR-71605Q SGL2274600-R
• Adaptec RAID 7805/7805Q/71605/71605Q/71605E External Alarm Connector: Molex 22-28-4023
or equivalent
• Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J6:
DescriptionSignalJ6 Pin Number
Open collector transistor~2kHz Square Wave2
—+3.3V1
Adaptec RAID 71685/72405/78165 Alarm Connector Specication
ASR-71685 SGL2274700-R
ASR-72405 SGL2274900-R
ASR-78165 SGL2280900-R
• Adaptec RAID 71685/72405/78165 External Alarm Connector: Molex 22-28-4023 or equivalent
• Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J6:
DescriptionSignalJ6 Pin Number
Open collector transistor~2kHz Square Wave2
—+3.3V1
107Proprietary and Condential to PMC-Sierra, Inc., and for its customers.
Document No.: CDP-00310-01-A Rev. A, Issue
