Warning: Do NOT remove or insert a fully charged supercapacitor module. Always discharge the unit
rst to avoid damage to the controller or ash backup module. The factory ships with discharged units,
so they are safe to install when you receive them. To ensure that an installed unit is discharged, switch
your system OFF, then wait 5 minutes. After a dirty shutdown, wait 3 minutes after backup is complete,
then remove the unit.
To install an Adaptec RAID controller with zero maintenance cache protection:
1. Assemble the mounting plate and attach the supercapacitor module:
a) Attach the full-height bracket and mounting clip to the mounting plate. The full-height bracket
is installed on the front side of the mounting plate (the side with the bents), with the mounting
screws inserted from the back, as shown in the gure below. (Be sure to attach the mounting
plate to the bracket with recessed side at the bottom!) Attach the mounting clip to the front of
the mounting plate with four (4) Phillips screws. The large friction clip should face the front of
the mounting plate.
Mounting clip
Recessed side
Large friction
clip
b) Insert the supercapacitor module into the mounting clip. The supercapacitor module snaps
securely into place between the large and small friction clips, as shown in the gure below. Be
sure to orient the supercapacitor module such that the connecting cable faces the rear of the
mounting plate.
c) Set the mounting plate aside; continue with the steps below.
2. Turn off your computer and disconnect the power cord. Open the cabinet, following the
manufacturer's instructions.
3. Select an available PCIe expansion slot that's compatible with your RAID controller and remove the
slot cover, as shown in the gure below. (PCIe bus compatibility is marked on the controller gures
in About Your RAID Controller on page 16.) Be sure to choose a slot in the backplane with an empty
slot next to it; you will use the empty slot to install the supercapacitor mounting plate, after you
install the controller. Remove the slot cover for the mounting plate, then continue with the next
step.
42Proprietary and Condential to PMC-Sierra, Inc., and for its customers.
Document No.: CDP-00310-01-A Rev. A, Issue
Serial Attached SCSI RAID Controllers Installation and User's Guide
