Preparation

NOTE: The pool must be set up on a completely flat and level surface. Please do not install the pool if the

surface is inclined or slope.

• Check with your local city council for by-laws relating to fencing, barriers, lighting and safety requirements and

ensure you comply with all laws.

• Take the pool and accessories out of the carton with care. If the pool set comes with a ladder, the ladder requires a

crosshead screwdriver or an adjustable wrench ( not included ) to assemble.

• Sand should not be used to create a level base, the ground should be dug out if necessary.

• Do not set pool up on driveways, decks, platforms, gravel or asphalt. Ground should be firm enough to withstand the

pressure of the water; mud, sand, soft / loose soil or tar are not suitable.

• The ground must be cleared of all objects and debris including stones and twigs.

NOTE: Lawn or other vegetation under the pool will die and may cause odors and slime, therefore we recommend

removing all grass from where

the pool will be located. Avoid locating your pool over or beside areas prone to aggressive plant and weed species

as they may grow through the ground cloth or liner.

• We highly recommend that once the pool is unfolded on the ground cloth to let it sit exposed to direct sunlight for 1

hour or more so that the pool is more flexible during set up.

Installation

Note: It is important to assemble pool in the order shown below.

1. If pool was purchased with a ground cloth, spread carefully at the desired location. Ensure the pool is located within

distance of a 220-240volt AC outlet protected by a RCD (Residual Current Device).

2. Spread out the pool and make sure the pool is right side up, let it sit exposed to direct sunlight for 1 hour or more so

that the pool is more flexible during set up.

3. Turn the pool so the drain valve is near the area where your plan to drain the water and pump valves are facing the RCD outlet.

ATTENTION: Do not drag the pool on the ground in order to avoid puncturing from sharp objects. Bestway Inflatables

will not be responsible for damage caused to the pool due to mishandling or failure to follow these instructions.

NOTE: The base or bottom of the pool should be laid out properly (flat without wrinkles).

Please see FAQ’s for additional information.

6. Ensure drain valve is firmly closed.

7. Put 1” to 2” water in the pool to cover the floor. Once pool floor is slightly covered, gently smooth out all wrinkles.

Start in the center of the pool and work your way clockwise to the outside.

Connection Valve Assembly

For 549cm x 122cm (18’ x 48”) pool model

1. Screw the Debris Screen onto the Connector. (See Fig. 2)

2. From inside the pool, insert this assembled Unit to the pool’s inlet A and outlet B. (See Fig. 3)

NOTE: Ensure the Gasket is properly in place on the assembled Unit inside of the pool liner.
