19 | english

12.2011 | C7 | Battery charger Automotive Aftermarket

Prior to start-up

3 Read the battery operating instructions before

connecting up the charger.

3 Observe the vehicle manufacturer's

recommendation if the battery is still

connected to the vehicle.

3 Clean the battery terminals. When doing so,

do not allow the dirt to come into contact

with your eyes or mouth.

3 Ensure adequate ventilation. Hydrogen gas

(electrolytic gas) may escape from the battery

during charging and trickle charging.

Connection

3 Connect the (+) terminal (red) (5) of the

charger to the (+) terminal of the battery.

3 Connect the (–) terminal (black) (6) of the

charger to the (–) terminal of the battery.

3 The (–) terminal (black) (6) can also be

connected to the car body, however well

away from fuel pipes.

Note: Make sure the (+) and (–) terminals are ﬁrm.

3 Only then is the power cord to be connected

to the mains current.

As soon as the charger has been connected to the

mains current, it switches automatically to standby

mode. The “Power” indicator will light up.

Note: The charger is provided with reverse

polarity protection. The LED (–)(+) (9) will light up

if the (+) and (–) terminals (5) (6) are interchanged

on connection.

Disconnection

3 Switch the charger to standby by pressing

the Mode selection button.

3 Always start by disconnecting the power cord

from the mains current.

3 Disconnect the (–) terminal (black) (6)

of the charger from the (–) terminal of the

battery.

3 Disconnect the (+) terminal (red) (5)

of the charger from the (+) terminal of the

battery.

Memory function

If the C7 charger is disconnected from the mains

during charging, the unit stores the mode imple-

mented. On re-connection to the mains and if the

battery is of the same type (12 V or 24 V), the unit

starts up automatically in the last mode. In the

case of a different type of battery (12 V and 24 V),

it switches to standby.

Caution: If mode 2 or 6 was last implemented

(cold battery or AGM battery) and a WET or GEL

battery is then connected, this may result in over-

charging and damage to the battery. In such cases

the mode is always to be set appropriately for

the battery to be charged. There is no memory

function with modes 3 and 4.

Operation
