Conguring SATA Hard Drive(s)

Step 5:

Enterthearraycapacityandpress<Enter>.Finallypress<Enter>ontheCreate Volume item to begin creating

theRAIDarray.Whenpromptedtoconrmwhethertocreatethisvolume,press<Y>toconrmor<N>to

cancel(Figure13).

Whencompleted,youcanseedetailedinformationabouttheRAIDarrayintheDISK/VOLUME INFORMATION

section,includingtheRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.(Figure14)

ToexittheRAIDBIOSutility,press<Esc>orselect6. Exit in MAIN MENU.

Now, you can proceed to install the SATA RAID/AHCI driver and operating system.

Figure 13

Figure 14

Intel(R) Rapid Storage Technology - Option ROM - 12.0.0.1783

Press ENTER to create the specied volume.

[

]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select

[ HELP ]

Name : Volume0

RAID Level : RAID0(Stripe)

Disks : Select Disks

Strip Size : 128 MB

Capacity : 111.7 GB

Sync : N/A

Create Volume

[ CREATE VOLUME MENU ]

WARNING : ALL DATA ON SELECTED DISKS WILL BE LOST.

Are you sure you want to create this volume? (Y/N) :

Intel(R) Rapid Storage Technology - Option ROM - 12.0.0.1783

RAID Volumes :

ID Name Level Strip Size Status Bootable

0 Volume0 RAID0(Stripe) 128KB 223.6GB Normal Yes

Physical Devices :

ID Device Model Serial # Size Type/Status(Vol ID)

0 ST3120026AS 3JT354CP 111.7GB Member Disk(0)

1 ST3120026AS 3JT329JX 111.7GB Member Disk(0)

[

]-Select [ESC]-Exit [ENTER]-Select Menu

[ DISK/VOLUME INFORMATION ]

[ MAIN MENU ]

4. Recovery Volume Options

5. Acceleration Options

6. Exit

1. Create RAID Volume

2. Delete RAID Volume

3. Reset Disks to Non-RAID
