Gigabyte ga-z87x-d3h [93/104] 1 2 configuring s pdif in out

- 93 -

Appendix

6-1-2 ConguringS/PDIFIn/Out

A. S/PDIF In

TheS/PDIFIncable(optional)allowsyoutoinputdigitalaudiosignalstothecomputerforaudioprocessing.

1. Connecting a S/PDIF In Cable:

Connect a S/PDIF in cable to the SPDIF_IN header on the motherboard as shown below.

2. Configuring S/PDIF In:

On the Digital Input screen, click the Default Format tab and then select the sample rate and bit depth. Click

OK to complete.
