![Gigabyte GA-970A-DS3 [23/44] Cpu frequency mhz](/views2/1168045/page23/bg17.png)
- 23 -
CPU Frequency(MHz) &
Allows you to manually set the CPU host frequency. The adjustable range is from 200 MHz to 500 MHz.
This option is congurable only when CPU Host Clock Control is set to Manual.
Important It is highly recommended that the CPU frequency be set in accordance with the CPU
specications.
PCIE Clock(MHz) &
Allows you to manually set the PCIe clock frequency. The adjustable range is from 100 MHz to 150
MHz.
Auto sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
HT Link Width &
Allows you to manually set the width for the HT Link between the CPU and chipset.
Auto BIOS will automatically adjust the HT Link Width. (Default)
8 bit Sets HT Link Width to 8 bit.
16 bit Sets HT Link Width to 16 bit.
HT Link Frequency &
Allows you to manually set the frequency for the HT Link between the CPU and chipset.
Auto BIOS will automatically adjust the HT Link Frequency. (Default)
x1~x13 Sets HT Link Frequency to x1~x13 (200 MHz~2.6 GHz).
DRAM E.O.C.P &
Allows you to determine whether to use the preset memory overclocking prole to achieve optimum
overclocking performance. (Default: Disabled)
Set Memory Clock &
Determines whether to manually set the memory clock. Auto lets BIOS automatically set the memory clock
as required. Manual allows the memory clock control item below to be congurable. (Default: Auto)
Memory Clock &
This option is congurable only when Set Memory Clock is set to Manual. The adjustable range is
dependent on the CPU being installed.
DRAM Conguration &
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
DRAMConguration
CPU Host Clock Control [Auto]
x CPU Frequency(MHz) 200
Set Memory Clock [Auto]
x Memory Clock x6.66 1333Mhz
DCTs Mode [Unganged]
DDR3 Timing Items [Auto] SPD Auto
x 1T/2T Command Timing Auto -- --
x CAS# latency Auto 9T 9T
x RAS to CAS R/W Delay Auto 9T 9T
x Row Precharge Time Auto 9T 9T
x Minimum RAS Active Time Auto 24T 24T
x TwTr Command Delay Auto 5T 5T
x Trfc0 for DIMM1, DIMM3 Auto 110ns 110ns
x Trfc1 for DIMM2, DIMM4 Auto -- --
x Write Recovery Time Auto 10T 10T
x Precharge Time Auto 5T 5T
x Row Cycle Time Auto 33T 33T
x RAS to RAS Delay Auto 4T 4T
**
DCTs Drive Strength
**
DCT0 DCT1
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
