![Gigabyte GA-970A-DS3 [31/44] Onboard audio function](/views2/1168045/page31/bg1f.png)
- 31 -
Port0 as ESP/Port1 as ESP/Port2 as ESP/Port3 as ESP &
This option is congurable only when OnChip SATA Type is set to AHCI. Enabled will speed up the hot
plug detection of the connected SATA device. (Default: Disabled)
Port4 as ESP/Port5 as ESP &
This option is congurable only when OnChip SATA Type is set to AHCI and OnChip SATA Type Port4/5
is set to As SATA Type. Enabled will speed up the hot plug detection of the connected SATA device.
(Default: Disabled)
SMART LAN (LAN Cable Diagnostic Function) &
Onboard LAN Function &
Enables or disables the onboard LAN function. (Default: Enabled) If you wish to install a 3rd party add-in
network card instead of using the onboard LAN, set this item to Disabled.
Onboard LAN Boot ROM &
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
This motherboard incorporates cable diagnostic feature designed to detect the status of the attached LAN cable.
This feature will detect cabling issue and report the approximate distance to the fault or short.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
SMART LAN
Start detecting at Port.....
Part1-2 Status = Open / Length = 0m
Part3-6 Status = Open / Length = 0m
Part4-5 Status = Open / Length = 0m
Part7-8 Status = Open / Length = 0m
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Onboard Audio Function &
Enables or disables the onboard audio function. (Default: Enabled)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item to
Disabled.
USB30 Controller (Etron EJ168 USB Controller) &
Enables or disables the Etron EJ168 USB controller. (Default: Enabled)
USB Controllers &
Enables or disables the integrated USB controllers. (Default: Enabled)
Disabled will turn off all of the USB functionalities below.
USB Legacy Function &
Allows USB keyboard to be used in MS-DOS. (Default: Enabled)
USB Storage Function &
Determines whether to detect USB storage devices, including USB ash drives and USB hard drives during
the POST. (Default: Enabled)
