- 8 -
1-2 Product Specications
CPU AM3+ Socket:
- AMD AM3+ FX processors
- AMD AM3 Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
4800 MT/s
Chipset
North Bridge: AMD 970
South Bridge: AMD SB950
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules
* To support a DDR3 1866 MHz (and above) memory, you must install an AM3+ CPU
rst.
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Audio Realtek HD audio codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
3 x PCI Express x1 slots
(All PCI Express slots conform to the PCI Express 2.0 standard.)
2 x PCI slots
Storage Interface South Bridge:
- 6 x SATA 6Gb/s connectors supporting up to 6 SATA 6Gb/s devices
- Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
USB South Bridge:
- Up to 12 USB 2.0/1.1 ports (6 ports on the back panel, 6 ports available
through the internal USB headers)
Etron EJ168 chip:
- Up to 2 USB 3.0/2.0 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
6 x SATA 6Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
