- 24 -
CPU Host Clock Control, CPU Frequency (MHz), Set Memory Clock, Memory Clock &
The settings under the four items above are synchronous to those under the same items on the MB Intelligent
Tweaker(M.I.T.) main menu.
DCTs Mode &
Allows you to set memory control mode.
Ganged Sets memory control mode to single dual-channel.
Unganged Sets memory control mode to two single-channel. (Default)
DDR3 Timing Items &
Manual allows all DDR3 Timing items below to be congurable.
Options are: Auto (default), Manual.
1T/2T Command Timing &
Options are: Auto (default), 1T, 2T.
CAS# latency &
Options are: Auto (default), 5T~14T.
RAS to CAS R/W Delay &
Options are: Auto (default), 2T~19T.
Row Precharge Time &
Options are: Auto (default), 2T~19T.
Minimum RAS Active Time &
Options are: Auto (default), 8T~40T.
TwTr Command Delay &
Options are: Auto (default), 4T~9T.
Trfc0 for DIMM1, DIMM3 &
Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.
Trfc1 for DIMM2, DIMM4 &
Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
DRAMConguration
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
ProcOdt(ohms) [Auto] 60 [Auto] 240
DQS Drive Strength [Auto] 1.0x [Auto] 1.0x
Data Drive Strength [Auto] 1.0x [Auto] 1.0x
MEMCLK Drive Strength [Auto] 1.25x [Auto] 1.25x
Addr/Cmd Drive Strength [Auto] 1.5x [Auto] 1.5x
CS/ODT Drive Strength [Auto] 1.5x [Auto] 1.5x
CKE Drive Strength [Auto] 1.5x [Auto] 1.5x
**
DCTs Addr/Cmd Timing
**
DCT0 DCT1
Addr/Cmd Setup Time [Auto] 1/2T [Auto] 1/2T
Addr/Cmd Fine Delay [Auto] 0/64 [Auto] 0/64
CS/ODT Setup Time [Auto] 1/2T [Auto] 1/2T
CS/ODT Fine Delay [Auto] 0/64 [Auto] 0/64
CKE Setup Time [Auto] 1/2T [Auto] 1/2T
CKE Fine Delay [Auto] 0/64 [Auto] 0/64
Channel Interleaving [Enabled]
Bank Interleaving [Enabled]
DQS Training Control [Skip DQS]
CKE Power Down Mode [Disabled]
Memclock tri-stating [Disabled]
