- 30 -
2-6 Integrated Peripherals
OnChip SATA Controller (AMD SB950 South Bridge, SATA3 0~5 connectors) &
Enables or disables the integrated SATA controller. (Default: Enabled)
OnChip SATA Type (AMD SB950 South Bridge, SATA3 0~3 connectors) &
Congures the operating mode of the integrated SATA3 0~3 controller.
Native IDE Allows the SATA controller to operate in Native IDE mode. (Default)
Enable Native IDE mode if you wish to install operating systems that support Native
mode.
RAID Enables RAID for the SATA controller.
AHCI Congures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
OnChip SATA Port4/5 Type (AMD SB950 South Bridge, SATA3 4/5 connectors) &
This option is congurable only when OnChip SATA Type is set to RAID or AHCI. Congures the operating
mode of the integrated SATA3 4/5 connectors.
IDE Disables RAID for the SATA controller and congures the SATA controller to PATA mode.
(Default)
As SATA Type The mode depends on the OnChip SATA Type settings.
OnChip SATA RAID5 Support (AMD SB950 South Bridge, SATA3 0~5 connectors) &
Enables or disables RAID 5 support for the SATA controller integrated in the AMD SB950 South Bridge.
This option is congurable only when OnChip SATA Type is set to RAID. (Default: Enabled)
OnChip SATA3.0 Support &
Enables or disables the SATA 6Gb/s function integrated in the South Bridge. When set to Disabled, the
SATA controller will operate in SATA 3Gb/s mode. (Default: Enabled)
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Integrated Peripherals
OnChip SATA Controller [Enabled]
OnChip SATA Type [Native IDE]
x OnChip SATA Port4/5 Type IDE
x OnChip SATA RAID5 Support Enabled
OnChip SATA3.0 Support [Enabled]
x OnChip SATA Port as ESP Press Enter
Onboard LAN Function [Enabled]
Onboard LAN Boot ROM [Disabled]
SMART LAN [Press Enter]
Onboard Audio Function [Enabled]
USB30 Controller [Enabled]
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
OnChip SATA Port as ESP &
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
OnChip SATA Port as ESP
Port0 as ESP [Disabled]
Port1 as ESP [Disabled]
Port2 as ESP [Disabled]
Port3 as ESP [Disabled]
x Port4 as ESP Disabled
x Port5 as ESP Disabled
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
