Gigabyte GA-970A-DS3 [39/44] Installing the sata raid driver and operating system
![Gigabyte GA-970A-DS3 [39/44] Installing the sata raid driver and operating system](/views2/1168045/page39/bg27.png)
- 39 -
When the next message appears, press <Ctrl>+<Y> to clear the MBR or press other keys to ignore this 6.
option.
Then, the message in Figure 3 will appear. Press <Ctrl>+<Y> to set the capacity of the RAID array or press 7.
other keys to set the array to its maximum capacity.
After the creation is complete, the screen will return to 8. LD View Menu where you will see the newly-
created array.
Press <Esc> to return to 9. Main Menu and press <Esc> again if you want to exit the RAID BIOS utility.
Figure 1
Figure 2
Figure 3
Please press Ctrl-Y key to input the LD Name
or press any key to exit.
If you do not input any LD name, the default
LD name will be used.
Fast Initialization Option has been selected
It will erase the MBR data of the disk.
<Press Ctrl-Y Key if you are sure to erase it>
<Press any other key to ignore this option>
Press Ctrl-Y to Modify Array Capacity or press any
other key to use maximum capacity...
Press <Ctrl>+<Y> keys to save the information. The message in Figure 1 will appear. Press <Ctrl>+<Y> to 5.
input the array name. If you do not input the array name, the default array name will be used.
Making a SATA RAID Driver Diskette
Before installing Windows XP, connect a USB oppy disk drive to your computer rst because you need to install
the SATA RAID/AHCI driver from a oppy disk that contains the driver during the OS installation. To copy the
RAID driver for Windows XP, copy all les in the \BootDrv\SBxxx\x86 folder in the motherboard driver disk to
your oppy disk. (To install Windows 64-bit, copy the les in the x64 folder.)
Installing the SATA RAID Driver and Operating System
A. Installing Windows XP
Restart your system to boot from the Windows XP setup disk and press <F6> as soon as you see the message
"Press F6 if you need to install a 3rd party SCSI or RAID driver." Insert the oppy disk containing the SATA RAID
driver. Follow the on-screen instructions to install the driver that suits your operating system. When completed,
proceed with the Windows XP installation.
B. Installing Windows 7/Vista
Restart your system to boot from the Windows 7/Vista setup disk and perform standard OS installation steps.
Select Load Driver. Insert the motherboard driver disk and then browse to the location of the driver. Then follow
the on-screen instructions to load the driver. The locations of the drivers for Windows 7 are as follows:
RAID driver for Windows 32-bit: \BootDrv\SBxxxW7\RAID\W7
RAID driver for Windows 64-bit: \BootDrv\SBxxxW7\RAID\W764A
After loading the driver, continue the OS installation.
