Hardware Installation - 10 -
1-2 Product Specications
CPU AM3+ Socket:
- AMD AM3+ FX processors
- AMD AM3 Phenom
™
II processors/ AMD Athlon
™
II processors
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
4400 MT/s
Chipset
North Bridge: AMD 760G
South Bridge: AMD SB710
Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1666 (O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Support for ECC memory modules
* Use of a CPU that supports ECC is required if you wish to install ECC memory.
Audio Realtek ALC887 codec
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out
LAN
1 x Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16
4 x PCI Express x1 slots
(All PCI Express slots conform to PCI Express 2.0 standard.)
2 x PCI slots
Storage Interface South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB South Bridge:
- Up to 10 USB 2.0/1.1 ports (6 ports on the back panel, 4 ports available
through the internal USB headers)
