- 6 -
Box Contents
GA-780T-D3L motherboard 5
Motherboard driver disk 5
User's Manual 5
Quick Installation Guide 5
Two SATA cables 5
I/O Shield 5
Optional Items
2-port USB 2.0 bracket (Part No. 12CR1-1UB030-5*R)
2-port SATA power cable (Part No. 12CF1-2SERPW-0*R)
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
