![Gigabyte GA-780T-D3L [72/96] Appendix 72](/views2/1168047/page72/bg48.png)
Appendix - 72 -
Create Arrays Manually
To create a new array, press <2> to enter the Define LD Menu window (Figure 4). The Define LD selection
from the Main Menu allows users to begin the process of manually defining the drive elements and RAID levels
for one or multiple disk arrays.
In Figure 4, use the up or down arrow key to move to a logical disk set and press <Enter> to enter the RAID
configuration menu (Figure 5).
Figure 4
Figure 5
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[DeneLDMenu]
LD No RAID Mode Total Drv Capacity (GB) Status
LD 1 ---- ---- ----- ----
LD 2 ---- ---- ----- ----
LD 3 ---- ---- ----- ----
LD 4 ---- ---- ----- ----
LD 5 ---- ---- ----- ----
LD 6 ---- ---- ----- ----
LD 7 ---- ---- ----- ----
LD 8 ---- ---- ----- ----
LD 9 ---- ---- ----- ----
LD 10 ---- ---- ----- ----
[h] Up [i] Down [ESC] Exit [Enter] Select
[ Keys Available ]
[ Keys Available ]
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[DeneLDMenu]
[h] Up [i] Down [ESC] Exit [Space] Change [Ctrl-Y] Save [PgUp/Dn] Page Change
[ Keys Available ]
[ Drives Assignments ]
Channel:ID Drive Model Capabilities Capacity (GB) Assignment
1:Mas WDC WD800JD-22LSA0 SATA 3G 79.89 N
2:Mas WDC WD800JD-22LSA0 SATA 3G 80.02 N
LD No RAID Mode Total Drv
LD 1 RAID 0 0
Stripe Block: 64 KB Fast Init: ON
Gigabyte Boundary: ON Cache Mode: WriteThru
