BIOS Setup - 32 -
CPU Frequency(MHz) &
Allows you to manually set the CPU host frequency. The adjustable range is from 200 MHz to 500 MHz.
This option is congurable only when CPU Host Clock Control is set to Manual.
Important It is highly recommended that the CPU frequency be set in accordance with the CPU
specications.
PCIE Clock(MHz) &
Allows you to manually set the PCIe clock frequency. The adjustable range is from 100 MHz to 150 MHz.
Auto sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
HT Link Frequency &
Allows you to manually set the frequency for the HT Link between the CPU and chipset.
Auto BIOS will automatically adjust the HT Link Frequency. (Default)
x1~x10 Sets HT Link Frequency to x1~x10 (200 MHz~2.0 GHz).
Set Memory Clock &
Determines whether to manually set the memory clock. Auto lets BIOS automatically set the memory clock
as required. Manual allows the memory clock control item below to be congurable. (Default: Auto)
Memory Clock &
This option is congurable only when Set Memory Clock is set to Manual. The adjustable range is
dependent on the CPU being installed.
DRAM Conguration
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
DRAMConguration
DCTs Mode [Unganged]
DDR3 Timing Items [Auto] SPD Auto
x 1T/2T Command Timing Auto -- --
x CAS# latency Auto 9T 6T
x RAS to CAS R/W Delay Auto 9T 6T
x Row Precharge Time Auto 9T 6T
x Minimum RAS Active Time Auto 24T 15T
x TwTr Command Delay Auto 5T 4T
x Trfc0 for DIMM1, DIMM3 Auto 90ns 90ns
x Trfc1 for DIMM2, DIMM4 Auto -- --
x Write Recovery Time Auto 10T 6T
x Precharge Time Auto 5T 4T
x Row Cycle Time Auto 33T 20T
x RAS to RAS Delay Auto 4T 4T
Channel Interleaving [Enabled]
Bank Interleaving [Enabled]
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
DCTs Mode &
Allows you to set memory control mode.
Ganged Sets memory control mode to single dual-channel.
Unganged Sets memory control mode to two single-channel. (Default)
DDR3 Timing Items &
Manual allows all DDR3 Timing items below to be congurable.
Options are: Auto (default), Manual.
