- 77 - Appendix
Step 2:
Insert the floppy disk containing the SATA RAID/AHCI driver and press <Enter>. Then a controller menu similar
to that in Figure 3 will appear. Select AMD AHCI Compatible RAID Controller-x86 platform and press
<Enter>.
Figure 3
Refer to the following for installing the driver during the Windows setup process.
Step 1:
Restart your system to boot from the Windows XP setup disk and press <F6> as soon as you see the message
"Press F6 if you need to install a 3rd party SCSI or RAID driver." A screen will then appear asking you to specify
an additional SCSI adapter. Press <S>.
Windows Setup
Youhave chosen to congure a SCSIAdapter for use withWindows,
using a device support disk provided by an adapter manufacturer.
Select the SCSI Adapter you want from the following list, or press ESC
to return to the previous screen.
ENTER=Select F3=Exit
AMD AHCI Compatible RAID Controller-x86 platform
AMD AHCI Compatible RAID Controller-x64 platform
Step 3:
On the next screen, press <Enter> to continue the driver installation. After the driver installation, you can proceed
with the Windows XP installation.
