- 45 - BIOS Setup
HDD S.M.A.R.T. Capability
Enables or disables the S.M.A.R.T. (Self Monitoring and Reporting Technology) capability of your hard
drive. This feature allows your system to report read/write errors of the hard drive and to issue warnings
when a third party hardware monitor utility is installed. (Default: Disabled)
Away Mode
Enables or disables Away Mode in Windows XP Media Center operating system. Away Mode allows the
system to silently perform unattended tasks while in a low-power mode that appears off.
(Default: Disabled)
Full Screen LOGO Show
Allows you to determine whether to display the GIGABYTE Logo at system startup. Disabled displays
normal POST message. (Default: Enabled)
IOMMU support
Enables or disables AMD IOMMU support. (Default: Disabled)
Init Display First
Species the rst initiation of the monitor display from the installed PCI graphics card or PCI Express
graphics card.
PCI Slot Sets the PCI graphics card as the rst display. (Default)
PEG Sets the PCI Express graphics card on the PCIEX16_1 slot as the rst display.
PEG1 Sets the PCI Express graphics card on the PCIEX16_2 slot as the rst display.
PEG2 Sets the PCI Express graphics card on the PCIEX4_1 slot as the rst display.
PEG3 Sets the PCI Express graphics card on the PCIEX4_2 slot as the rst display.
