- 7 -
GA-990FXA-UD3 Motherboard Layout
KB_MS_USB
CPU_FAN
Socket AM3+
ATX
GA-990FXA-UD3
AUDIO
DDR3_4
DDR3_2
BAT
ATX_12V
AMD 990FX
R_USB30
CODEC
PWR_FAN
OPTICAL
USB_1394_ESATA
USB_ESATA
USB_LAN
B_BIOS
M_BIOS
CLR_CMOS
Realtek
RTL8111E
Etron
EJ168
iTE
IT8720
DDR3_3
DDR3_1
F_USB2
F_USB30
TPM
F_PANEL
F_USB1F_USB3
SYS_FAN2
F_1394
SPDIF_O
F_AUDIO
COMA
AMD SB950
SATA3_4
SATA3_2
SATA3_0
SATA3_5
SATA3_3
SATA3_1
SYS_FAN1
Etron
EJ168
VIA
VT6308
PCIEX1_1
PCIEX16_1
PCIEX1_2
PCIEX4_1
PCIEX16_2
PCI
PCIEX4_2
Marvell 88SE9172
