- 47 - BIOS Setup
OnChip SATA Port as ESP
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
OnChip SATA Port as ESP
Port0 as ESP [Disabled]
Port1 as ESP [Disabled]
Port2 as ESP [Disabled]
Port3 as ESP [Disabled]
Port4 as ESP [Disabled]
Port5 as ESP [Disabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Port0 as ESP/Port1 as ESP/Port2 as ESP/Port3 as ESP
This option is congurable only when OnChip SATA Type is set to AHCI. Enabled will speed up the hot
plug detection of the connected SATA device. (Default: Disabled)
Port4 as ESP/Port5 as ESP
This option is congurable only when OnChip SATA Type is set to AHCI and OnChip SATA Type
Port4/5 is set to as SATA Type. Enabled will speed up the hot plug detection of the connected SATA
device. (Default: Disabled)
F_USB30 Controller (Etron EJ168 USB controller, USB 3.0/2.0 ports routed to the on-
board F_USB30 header)
Enables or disables the Etron EJ168 USB controller. (Default: Enabled)
eSATA3 Controller (Marvell 88SE9172 chip, eSATA connectors on the back panel)
Enables or disables the SATA controller integrated in the Marvell 88SE9172 chip. (Default: Enabled)
eSATA3 Ctrl Mode (
Marvell 88SE9172
chip, eSATA connectors on the back panel)
Enables or disables RAID for the SATA controller integrated in the Marvell 88SE9172 chip or congures
the SATA controller to AHCI mode.
IDE Disables RAID for the SATA controller and congures the SATA controller to IDE
mode. (Default)
AHCI Congures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
RAID Enables RAID for the SATA controller.
