BIOS Setup - 46 -
2-6 Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Integrated Peripherals
OnChip SATA Controller [Enabled]
OnChip SATA Type [Native IDE]
x OnChip SATA Port4/5 Type IDE
x OnChip SATA RAID5 Support Enabled
OnChip SATA3.0 Support [Enabled]
x OnChip SATA Port as ESP Press Enter
F_USB30 Controller [Enabled]
eSATA3 Controller [Enabled]
eSATA3 Ctrl Mode [IDE]
Onboard LAN Function [Enabled]
Onboard LAN Boot ROM [Disabled]
SMART LAN [Press Enter]
Onboard Audio Function [Enabled]
Onboard 1394 Function [Enabled]
R_USB30 Controller [Enabled]
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
Onboard Serial Port 1 [3F8/IRQ4]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
OnChip SATA Controller (AMD SB950, SATA3_0~SATA3_5 connectors)
Enables or disables the integrated SATA controller. (Default: Enabled)
OnChip SATA Type (AMD SB950, SATA3_0~SATA3_3 connectors)
Congures the operating mode of the SATA3_0~SATA3_3 connectors.
Native IDE Allows the SATA controller to operate in Native IDE mode. (Default)
Enable Native IDE mode if you wish to install operating systems that support Native
mode.
RAID Enables RAID for the SATA controller.
AHCI Congures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
OnChip SATA Port4/5 Type (AMD SB950, SATA3_4 and SATA3_5 connectors)
This option is congurable only when OnChip SATA Type is set to RAID or AHCI. Congures the oper-
ating mode of the integrated SATA3_4 and SATA3_5 connectors.
IDE Disables RAID for the SATA controller and congures the SATA controller to IDE
mode. (Default)
As SATA Type The mode depends on the OnChip SATA Type settings.
OnChip SATA RAID5 Support (AMD SB950, SATA3_0~SATA3_5 connectors)
Enables or disables RAID 5 support for the SATA controller integrated in the AMD SB950 South Bridge.
This option is congurable only when OnChip SATA Type is set to RAID.
OnChip SATA3.0 Support
Enables or disables the SATA 6Gb/s function integrated in the South Bridge. When set to Disabled, the
SATA controller will operate in SATA 3Gb/s mode. (Default: Enabled)
