- 85 - Appendix
To exit the RAID BIOS utility, press <Esc> on the main screen and press <Y> to conrm.
Now, you can proceed to install the operating system.
When completed, the RAID tab will display the new array. (Figure 8)
Figure 8
Delete the RAID Array:
To deleted the existing array, press <Enter> on the RAID tab and select Delete VD. When the Delete VD menu
appears, press <Enter> on the array to select it and then press <Enter> on NEXT. When prompted, press <Y>
to conrm (Figure 9).
When the message "Do you want to delete the VD's MBR?" appears, press <Y> to
clear the MBR or press other keys to ignore.
Figure 9
[ Selection] [ Adapter] [ Devices] [ RAID ]
Marvell BIOS Setup (C) 2009 Marvell Technology Group Ltd.
RAIDCong
ID Name Size Level Status Stripe CacheMode
* 0 GBT 152.4GB RAID0 ONLINE 64KB WriteBack
NEXT
Delete VD
Delete the VD?[Y]
ENTER/SPACE: Select, ESC: Back/Exit
[ Selection]
[ Adapter]
[ Devices]
[ RAID ]
[Virtual Disks]
ID Name Size Level Status Stripe CacheMode
0 GBT 152.4GB RAID0 ONLINE 64KB WriteBack
[Physical Disks]
Port Disk Name Size Max Speed Status
S0 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s ASSIGNED
S1 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s ASSIGNED
Marvell BIOS Setup (c) 2009 Marvell Technology Group Ltd.
