Appendix - 84 -
Step 3: On the Create VD menu (Figure 6), use the up or down arrow key to move the selection bar to select
an item and press <Enter> to display options. Set the required items in sequence and press the down arrow
key to proceed to the next item.
Sequence:
1. RAID Level: Select a RAID level. Options include RAID 0 (Stripe) and RAID 1 (Mirror).
2. Stripe Size: Select the stripe block size. Options include 32 KB, 64 KB, and 128 KB.
3. Quick Init: Select whether to quickly erase old data on the hard drives when creating the array.
4. Cache Mode: Select write-back or write-through cache.
5. VD Name: Enter an array name with 1~10 letters (letters cannot be special characters).
Figure 6
Figure 7
6. NEXT: After completing the settings above, move to NEXT and press <Enter> to begin creating the array.
When prompted to conrm, press <Y> to conrm or <N> to cancel (Figure 7).
ENTER/SPACE: Select, ESC: Back/Exit
[ Selection] [ Adapter] [ Devices] [ RAID ]
Marvell BIOS Setup (c) 2009 Marvell Technology Group Ltd.
RAIDCong
Port Disk Name Size Max Speed Status
* S0 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
* S1 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
Select free disks to create
RAID Level :
Max Size (MB): 152478
Stripe Size : 64KB
Quick Init : NO
Cache Mode : WriteBack
VD Name :
Disks ID : 01
NEXT
Create VD
RAID0
[ Selection] [ Adapter] [ Devices] [ RAID ]
RAIDCong
Port Disk Name Size Max Speed Status
* S0 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
* S1 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
NEXT
Select free disks to create
RAID Level : RAID0
Max Size (MB): 152478
Stripe Size : 64KB
Quick Init : NO
Cache Mode : WriteBack
VD Name : GBT
Disk ID : 01
Create VD
NEXT
Marvell BIOS Setup (c) 2009 Marvell Technology Group Ltd.
Create the VD?[Y]
