![Gigabyte GA-990FXA-UD3 [90/112] Appendix 90](/views2/1168049/page90/bg5a.png)
Appendix - 90 -
Step 2:
For the AMD SB950:
Insert the oppy disk containing the SATA RAID/AHCI driver and press <Enter>. Then a controller menu simi-
lar to that in Figure 4 will appear. Select AMD AHCI Compatible RAID Controller-x86 platform and press
<Enter>.
Figure 4
Refer to the following for installing the driver during the Windows setup process.
Step 1:
Restart your system to boot from the Windows XP setup disk and press <F6> as soon as you see the mes-
sage "Press F6 if you need to install a 3rd party SCSI or RAID driver." A screen will then appear asking you to
specify an additional SCSI adapter. Press <S>.
Windows Setup
YouhavechosentocongureaSCSIAdapterforusewithWindows,
using a device support disk provided by an adapter manufacturer.
Select the SCSI Adapter you want from the following list, or press ESC
to return to the previous screen.
ENTER=Select F3=Exit
AMD AHCI Compatible RAID Controller-x86 platform
AMD AHCI Compatible RAID Controller-x64 platform
