Chapter 33 Link Layer Discovery Protocol (LLDP)
GS1920 Series User’s Guide
275
33.4 LLDP Local Status
This screen displays a summary of LLDP status on this Switch. Click Advanced Application >
LLDP > LLDP Local Status to display the screen as shown next.
Figure 193 Advanced Application > LLDP > LLDP Local Status
LLDP-MED
Network Policy
Click here to show a screen to configure LLDP-MED (Link Layer Discovery Protocol for
Media Endpoint Devices) network policy parameters.
LLDP-MED
Location
Click here to show a screen to configure LLDP-MED (Link Layer Discovery Protocol for
Media Endpoint Devices) location parameters.
Table 127 Advanced Application > LLDP (continued)
LABEL DESCRIPTION
