Chapter 7 Status and ZON
GS1920 Series User’s Guide
61
Length This field shows the number of packets received with a length that was out of range.
Runt This field shows the number of packets received that were too short (shorter than 64 octets),
including the ones with CRC errors.
Distribution
64 This field shows the number of packets (including bad packets) received that were 64 octets
in length.
65-127 This field shows the number of packets (including bad packets) received that were between
65 and 127 octets in length.
128-255 This field shows the number of packets (including bad packets) received that were between
128 and 255 octets in length.
256-511 This field shows the number of packets (including bad packets) received that were between
256 and 511 octets in length.
512-1023 This field shows the number of packets (including bad packets) received that were between
512 and 1023 octets in length.
1024-
1518
This field shows the number of packets (including bad packets) received that were between
1024 and 1518 octets in length.
Giant This field shows the number of packets (including bad packets) received that were between
1519 octets and the maximum frame size.
The maximum frame size varies depending on your switch model.
Table 10 Port Status: Port Details (continued)
LABEL DESCRIPTION
