Chapter 23 VLAN Stacking
MES3500/MGS3520 Series User’s Guide
174
Priority This is the service provider’s priority level in the packets.
Delete Check the rule(s) that you want to remove in the Delete column and then click the Delete button.
Cancel Click Cancel to clear the Delete check boxes.
Table 60 Advanced Application > VLAN Stacking > Selective QinQ (continued)
LABEL DESCRIPTION
