Chapter 26 IP Source Guard
MES3500/MGS3520 Series User’s Guide
210
26.5 DHCP Snooping Configure
Use this screen to enable DHCP snooping on the Switch (not on specific VLAN), specify the VLAN
where the default DHCP server is located, and configure the DHCP snooping database. The DHCP
snooping database stores the current bindings on a secure, external TFTP server so that they are
still available after a restart. To open this screen, click Advanced Application > IP Source Guard
> DHCP Snooping > Configure.
Parse failures This field displays the number of bindings the Switch ignored because the Switch was
unable to understand the binding in the DHCP binding database.
Expired leases This field displays the number of bindings the Switch ignored because the lease time
had already expired.
Unsupported vlans This field displays the number of bindings the Switch ignored because the VLAN ID
does not exist anymore.
Last ignored time This field displays the last time the Switch ignored any bindings for any reason from
the DHCP binding database.
Total ignored bindings
counters
This section displays the reasons the Switch has ignored bindings any time it read
bindings from the DHCP binding database. You can clear these counters by restarting
the Switch or using CLI commands. See the Ethernet Switch CLI Reference Guide.
Binding collisions This field displays the number of bindings the Switch has ignored because the Switch
already had a binding with the same MAC address and VLAN ID.
Invalid interfaces This field displays the number of bindings the Switch has ignored because the port
number was a trusted interface or does not exist anymore.
Parse failures This field displays the number of bindings the Switch has ignored because the Switch
was unable to understand the binding in the DHCP binding database.
Expired leases This field displays the number of bindings the Switch has ignored because the lease
time had already expired.
Unsupported vlans This field displays the number of bindings the Switch has ignored because the VLAN
ID does not exist anymore.
Table 78 DHCP Snooping (continued)
LABEL DESCRIPTION
