Chapter 24 Multicast
MES3500/MGS3520 Series User’s Guide
176
24.1.4 IGMP Snooping and VLANs
The Switch can perform IGMP snooping on up to 16 VLANs. You can configure the Switch to
automatically learn multicast group membership of any VLANs. The Switch then performs IGMP
snooping on the first 16 VLANs that send IGMP packets. This is referred to as auto mode.
Alternatively, you can specify the VLANs that IGMP snooping should be performed on. This is
referred to as fixed mode. In fixed mode the Switch does not learn multicast group membership of
any VLANs other than those explicitly added as an IGMP snooping VLAN.
24.2 Multicast Status
Click Advanced Applications > Multicast to display the screen as shown. This screen shows the
multicast group information. See Section 24.1 on page 175 for more information on multicasting.
Figure 98 Advanced Application > Multicast
The following table describes the labels in this screen.
24.3 Multicast Setting
Click Advanced Applications > Multicast > Multicast Setting link to display the screen as
shown. See Section 24.1 on page 175 for more information on multicasting.
Table 61 Multicast Status
LABEL DESCRIPTION
Index This is the index number of the entry.
VID This field displays the multicast VLAN ID.
Port This field displays the port number that belongs to the multicast group.
Multicast Group This field displays IP multicast group addresses.
