Chapter 4 The Web Configurator
MES3500/MGS3520 Series User’s Guide
38
General Setup This link takes you to a screen where you can configure general identification information
and time settings for the Switch.
Switch Setup This link takes you to a screen where you can set up global Switch parameters such as
VLAN type, MAC address learning, GARP and priority queues.
IP Setup This link takes you to a screen where you can configure the management IP address,
subnet mask (necessary for Switch management) and DNS (domain name server).
Port Setup This link takes you to screens where you can configure speed, flow control and priority
settings for individual Switch ports.
Advanced Application
VLAN This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu). You can also configure a
protocol based VLAN or a subnet based VLAN in these screens.
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses for a port.
These static MAC addresses do not age out.
Static Multicast
Forwarding
This link takes you to a screen where you can configure static multicast MAC addresses
for port(s). These static multicast MAC addresses do not age out.
Filtering This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the RSTP/MRSTP/MSTP to prevent
network loops.
Bandwidth Control This link takes you to screens where you can cap the maximum bandwidth allowed on a
port.
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring This link takes you to screens where you can copy traffic from one port or ports to
another port in order that you can examine the traffic from the first port without
interference.
Link Aggregation This link takes you to screen where you can logically aggregate physical links to form one
logical, higher-bandwidth link.
Port
Authentication
This link takes you to a screen where you can configure IEEE 802.1x port authentication
as well as MAC authentication for clients communicating via the Switch.
Port Security This link takes you to a screen where you can activate MAC address learning and set the
maximum number of MAC addresses to learn on a port.
Classifier This link takes you to a screen where you can configure the Switch to group packets
based on the specified criteria.
Policy Rule This link takes you to a screen where you can configure the Switch to perform special
treatment on the grouped packets.
Queuing Method This link takes you to a screen where you can configure queuing with associated queue
weights for each port.
VLAN Stacking This link takes you to screens where you can activate and configure VLAN stacking.
Multicast This link takes you to screen where you can configure various multicast features, IGMP
snooping and create multicast VLANs.
AAA This link takes you to a screen where you can configure authentication, authorization and
accounting services via external servers. The external servers can be either RADIUS
(Remote Authentication Dial-In User Service) or TACACS+ (Terminal Access Controller
Access-Control System Plus).
IP Source Guard This link takes you to screens where you can configure filtering of unauthorized DHCP and
ARP packets in your network.
Loop Guard This link takes you to a screen where you can configure protection against network loops
that occur on the edge of your network.
Table 5 Navigation Panel Links (continued)
LINK DESCRIPTION
