![Zyxel MGS3520-28F [262/338] Dhcp relay](/views2/1169495/page262/bg106.png)
Chapter 36 DHCP
MES3500/MGS3520 Series User’s Guide
262
36.3 DHCP Relay
Configure DHCP relay on the Switch if the DHCP clients and the DHCP server are not in the same
broadcast domain. During the initial IP address leasing, the Switch helps to relay network
information (such as the IP address and subnet mask) between a DHCP client and a DHCP server.
Once the DHCP client obtains an IP address and can connect to the network, network information
renewal is done between the DHCP client and the DHCP server without the help of the Switch.
The Switch can be configured as a global DHCP relay. This means that the Switch forwards all DHCP
requests from all domains to the same DHCP server. You can also configure the Switch to relay
DHCP information based on the VLAN membership of the DHCP clients.
vlan Select this option to have the Switch add the ID of VLAN which the port belongs to.
hostname This is the system name you configure in the Basic Setting > General Setup screen.
Select this option for the Switch to add the system name to the client DHCP requests that it
relays to a DHCP server.
string Enter a string of up to 64 ASCII characters that the Switch adds into the client DHCP
requests. Spaces are allowed.
Remote-ID Use this section to configure the Remote ID sub-option to include information that identifies
the relay agent (the Switch).
Enable Select this option to have the Switch append the Remote ID sub-option to the option 82 field
of DHCP requests.
mac Select this option to have the Switch add its MAC address to the client DHCP requests that it
relays to a DHCP server.
string Enter a string of up to 64 ASCII characters for the remote ID information in this field.
Spaces are allowed.
Add Click this to create a new entry or to update an existing one.
This saves your changes to the Switch’s run-time memory. The Switch loses these changes if
it is turned off or loses power, so use the Save link on the top navigation panel to save your
changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to reset the fields to their last saved values.
Profile Name This field displays the descriptive name of the profile. Click the name to change the settings.
Circuit-ID
Enable This field displays whether the Circuit ID sub-option is added to client DHCP requests.
Field This field displays the information that is included in the Circuit ID sub-option.
Remote-ID
Enable This field displays whether the Remote ID sub-option is added to client DHCP requests.
Field This field displays the information that is included in the Remote ID sub-option.
Delete Check the entry(ies) that you want to remove in the Delete column and then click the
Delete button.
Cancel Click Cancel to clear the selected checkbox(es) in the Delete column.
Table 114 IP Application > DHCP > Option 82 Profile (continued)
LABEL DESCRIPTION
