4.7.1 At the Power Box Location:

• Connect the DC Cable from the Power Box to

the 15 m (50 ft.) Extension Cable.

• Connect the Power Box to a regular power

outlet (230V / 120V).

) The Docking Indicator will light up if the mower is in the

Base Station.

) The Operating Indicator will light up if the mower is not in

the Base Station.

Docking Indicator

Automatic

Operation

Operating

Indicator

Wire Indicator
