Introduction
Stitch Overview
Utility Stitches
Stitch
№ Name
Description
1
Straight stitch For seaming and topstitching. Select from 29 different needle positions.
2
Stretch triple straight
stitch
Reinforced seam. Topstitching.
3
Straight stitch reverse
Sew continuous reverse.
4
Zigzag stitch Reinforce seams, clean finish, stretch sewing, lace insertion.
5
Zigzag stitch, right or
left needle position
Reinforce seams, clean finish, stretch sewing.
6
Z-zigzag stitch Appliqué, couching, eyelets.
7
Stretch triple zigzag
stitch
Elastic stitch for decorative hems or topstitching.
8
Three-step zigzag
stitch
Sewing elastic, darning, patching.
9
Elastic stitch Sewing elastic, darning, patching.
10
Triple stretch stitch Sewing elastic, darning, patching and decorative sewing.
11
Honeycomb stitch Decorative stitch for stretch fabrics and hems. Also used with elastic
thread in the bobbin.
12
Bridging stitch Joining fabrics and quilt batting, decorative stitch for quilting,
hemstitching.
13
Foundation elastic
stitch
Joining stitch for undergarments, terry cloth, leather, bulky fabrics where
overlapping the seams.
14
Crosshem stitch Elastic decorative hem for stretch fabrics.
15
Blindhem stitch Sewing blindhems on woven fabrics.
16
Elastic blindhem
stitch
Sewing blindhems on stretch fabrics.
17
Stretch tricot stitch Sewing seams on stretch fabrics.
18
Closed overlock Seam and overcast stretch fabrics in one step.
19
Closed overlock Seam and overcast in one step with reinforced edge.
11
