Pfaff creative 1.5 [31/68] Preparations
![Pfaff creative 1.5 [31/68] Preparations](/views2/1176989/page31/bg1f.png)
Preparations
When turning on the machine with this setting activated
and for every stitch selection that is not a straight stitch,
a pop-up informs you that the machine is set to straight
stitch.
Note: Twin needle and stitch width safety cannot be used at
the same time.
Automatic Stop for Cut
(Only in embroidery mode)
When starting to embroider the machine stops after a
few stitches asking you to cut the thread end. Use the
OK button to turn on or off this function in the settings
menu.
Note: Automatic stop for cut is disabled if you use the foot
control when embroidering.
Language
Use the left and right arrow buttons to change the
language of all text in your machine.
Audible Alarm
Turn all alarm sounds of the machine on or off. Default
setting is on.
Contrast
Adjust the contrast of the graphic display by using the
left and right arrow buttons. The value can be set
between -3 to 4 in steps of 1.
Software Version
Check the software version for your sewing machine.
Hoop Positions
(Only in embroidery mode)
Use the hoop position functions to move the hoop to
different positions.
Current Position
When you want to return to the current stitch and start
embroidering again where the embroidery was
interrupted, use the wheel to select the current position
and press OK. You can also press the start/stop button
once to return to the current stitch and start to
embroider.
31
