Embroidering
Note: If you try to start embroidering and the hoop you have
selected is not the same as the hoop attached to the embroidery
unit, a pop-up will appear to inform you of this. Attach the
correct hoop or select another hoop in the list.
Hoop Positions
Open the settings menu to choose between different
hoop positions.
Current Position
When you want to return to the current stitch and start
embroidering again where the embroidery was
interrupted, select the current position option. You can
also press the start/stop button once to return to the
current stitch and start to embroider.
Park Position
When you have finished your embroidery, remove the
hoop and select the park position option.
It is very important that the hoop is removed,
otherwise it may be damaged.
Cut Position
Cut position will move the hoop towards you, making it
easier to trim fabric when embroidering an appliqué.
Center Position
Use the center position if you want to move the needle
to the center position of the hoop.
Stitches Left in Color Block
Stitch-out view 1
The two values shown in the center position on the right
side of the display indicate the number of stitches left in
the current color block and the number of stitches left in
the design (shown in brackets). Press the + or - buttons
to step forward or backward stitch by stitch through the
design. Step backwards a few stitches if the needle
thread breaks or runs out.
Current Color
Stitch-out view 1
The values displayed in the lower right corner denote
the current color block and the total number of color
blocks in the design (shown in brackets). Use the + and -
buttons to move forward or backward through the color
blocks.
52
