Yealink IP Phones Auto provisioning Guide
142
Parameter
Permitted Values
Descriptions
Web Setting Path
6-Line 6
Lines 4-6 are only applicable to SIP-T28P,
SIP-T48G and SIP-T46G IP phones.
The default value is 1.
expansion_module.X.key.Y.value =
(SIP-T28P/T48G/T46G: X ranges from 1 to 6.
SIP-T26P: X ranges from 1 to 3.
Y ranges from 1 to 40)
(only applicable to SIP-T28P, SIP-T26P, SIP-T48G and
SIP-T46G IP phones)
String within 99
characters
It configures the value of the expansion
module key feature.
The default value is blank.
DSSKey->Ext Key->Value
expansion_module.X.key.Y.pickup_value =
(SIP-T28P/T48G/T46G: X ranges from 1 to 6.
SIP-T26P: X ranges from 1 to 3.
Y ranges from 1 to 40)
(only applicable to SIP-T28P, SIP-T26P, SIP-T48G and
SIP-T46G IP phones)
String within 255
characters
It configures the pickup code for BLF feature
or conference ID followed by the # sign for
Meet-Me conference feature.
It only applies to BLF and Meet-Me
conference features.
The default value is blank.
DSSKey->Ext Key->Extension
expansion_module.X.key.Y.label =
(SIP-T28P/T48G/T46G: X ranges from 1 to 6.
SIP-T26P: X ranges from 1 to 3.
Y ranges from 1 to 40)
String within 99
characters
It configures the label displayed on the LCD
screen of the expansion module for each
key.
The default value is blank.
DSSKey->Ext Key->Label
