Yealink IP Phones Auto provisioning Guide
84
Parameter
Permitted Values
Descriptions
Web Setting Path
network.vlan.internet_port_enable =
0 or 1
It enables or disables VLAN of the Internet
(WAN) port.
0-Disabled
1-Enabled
The default value is 0.
It takes effect after a reboot.
Network-> Advanced->VLAN ->WAN
Port-> Active
network.vlan.internet_port_vid =
Integer from 1 to
4094
It configures VLAN ID of the Internet (WAN)
port.
The default value is 1.
It takes effect after a reboot.
Network-> Advanced->VLAN ->WAN
Port->VID (1-4094)
network.vlan.internet_port_priority =
Integer from 0 to 7
It configures VLAN priority of the Internet
(WAN) port.
The default value is 0.
It takes effect after a reboot.
Network-> Advanced->VLAN ->WAN
Port-> Priority
network.vlan.pc_port_enable =
(not applicable to CP860 IP phones)
0 or 1
It enables or disables VLAN of the PC (LAN)
port.
0-Disabled
1-Enabled
The default value is 0.
It takes effect after a reboot.
Network-> Advanced->VLAN >PC
Port->Active
