Appendix
81
Parameter
Permitted Values
Descriptions
Web Setting Path
network.bridge_mode =
(only applicable to SIP-T28P, SIP-T26P, SIP-T22P and
SIP-T20P IP phones)
0 or 1
It configures the PC (LAN) port type.
0-Router
1-Bridge
The default value is 1.
It takes effect after a reboot.
Note: SIP-T19P/T21P/T48G/T46G/ T42G/T41P/
IP phones only support bridge mode for PC
connection.
Network->PC Port ->PC Port Config
network.pc_port.enable =
(not applicable to CP860 IP phones)
0 or 1
It enables or disables the PC port.
0-Disabled
1-Auto Negotiation
The default value is 1.
It takes effect after a reboot.
Network->PC Port ->PC Port Active
network.pc_port.ip =
(only applicable to SIP-T28P, SIP-T26P, SIP-T22P and
SIP-T20P IP phones)
IP address
It configures the IP address of the PC (LAN)
port when the PC (LAN) port is configured as
Router.
The default value is 10.0.0.1.
It takes effect after a reboot.
Network->PC Port ->PC Port Config
->As Router->IP Address
network.pc_port.mask =
(only applicable to SIP-T28P, SIP-T26P, SIP-T22P and
IP address
It configures the mask of the PC (LAN) port
when the PC (LAN) port is configured as
Network->PC Port ->PC Port Config
->As Router ->Subnet Mask
