Yealink IP Phones Auto provisioning Guide
276
The following tables list relationship between the values of X in the following parameters and programmable keys for each phone model.
# X ranges from 1 to 14.
programablekey.X.type =
programablekey.X.line =
programablekey.X.value =
programablekey.X.xml_phonebook =
programablekey.X.history_type =
programablekey.X.pickup_value =
# X ranges from 1 to 4.
programablekey.X.label =
SIP-T19P
SIP-T20P
SIP-T21P/T22P
SIP-T28/T26P
SIP-T42G/T41P
SIP-T48G/T46G
CP860
1
SoftKey1
SoftKey1
SoftKey1
SoftKey1
SoftKey1
SoftKey1
2
SoftKey2
SoftKey2
SoftKey2
SoftKey2
SoftKey2
SoftKey2
3
SoftKey3
SoftKey3
SoftKey3
SoftKey3
SoftKey3
SoftKey3
4
SoftKey4
SoftKey4
SoftKey4
SoftKey4
SoftKey4
SoftKey4
5
Up
Up
Up
Up
Up
Up
Up
X
Phone Model
