Yealink IP Phones Auto provisioning Guide
82
Parameter
Permitted Values
Descriptions
Web Setting Path
SIP-T20P IP phones)
Router.
The default value is 255.255.255.0.
It takes effect after a reboot.
network.pc_port.dhcp_server =
(only applicable to SIP-T28P, SIP-T26P, SIP-T22P and
SIP-T20P IP phones)
0 or 1
It enables or disables the phone to act as a
DHCP server when the PC (LAN) port is
configured as Router.
0-Disabled
1-Enabled
The default value is 1.
It takes effect after a reboot.
Network->PC Port ->PC Port Config
->As Router ->Enable DHCP Server
network.dhcp.start_ip =
(only applicable to SIP-T28P, SIP-T26P, SIP-T22P and
SIP-T20P IP phones)
IP address
It configures the start IP address of the
DHCP IP segment.
The default value is 10.0.0.10.
It takes effect after a reboot.
Network->PC Port ->PC Port Config
->As Router->Start IP Address
network.dhcp.end_ip =
(only applicable to SIP-T28P, SIP-T26P, SIP-T22P and
SIP-T20P IP phones)
IP address
It configures the end IP address of the DHCP
IP segment.
The default value is 10.0.0.100.
It takes effect after a reboot.
Network->PC Port ->PC Port Config
->As Router->End IP Address
network.internet_port.speed_duplex =
0, 1, 2, 3, 4 or 5
It configures the transmission mode and
speed of the Internet (WAN) port.
Network-> Advanced->Port Link->
WAN Port Link
