Yealink IP Phones Auto provisioning Guide
194
Parameter
Permitted Values
Descriptions
Web Setting Path
0-Disabled (power indicator LED does not
flash)
1-Enabled (power indicator LED fast flashes
(300ms) red)
The default value is 0.
If it is set to 0, the status of the power
indicator LED is determined by the value of
the parameter
“phone_setting.common_power_led_enabl
e”.
phone_setting.hold_and_held_power_led_flash_en
able =
(not applicable to CP860 IP phones)
0 or 1
It enables or disables the power indicator
LED to flash when a call is placed on hold or
is held.
For SIP-T2xP/T19P IP phones:
0-Disabled (power indicator LED does not
flash)
1-Enabled (power indicator LED fast flashes
(500ms) green)
The default value is 0.
For SIP-T4X IP phones:
0-Disabled (power indicator LED does not
Features->Power LED->Hold/Held
Power Light On
