Graco Python XL 5/8" [40/48] Pneumatic valve parts
Parts
40 3A3948B
Pneumatic Valve Parts
Complete Pneumatic Valve Replacement Kit 24A351
To replace the complete pneumatic valve, order Pneumatic Valve Replacement Kit 24A351. The kit includes items
301-312 below, and items 209 and 211 on page 38.
Pneumatic Valve Repair Kits
Pneumatic valve parts are not sold individually. The table below shows possible kit options for each part.
† Included in Pneumatic Valve Seal Kit 24A535.
Included in Pneumatic Valve Repair Kit 24A537.
Included in Pneumatic Valve End Cap Kit 24A360.
Replacement screws (309) are available in a pack of 10. Order Kit 24A359.
Ref. Description Qty.
Pneumatic Valve
Repair Kit
24A537
Pneumatic Valve
Seal Kit
24A535
Pneumatic Valve
End Cap Kit
24A360
301 HOUSING 1
302 PNEUMATIC VALVE PISTON 1
303 DETENT PISTON ASSEMBLY 1
304 DETENT CAM 1
305 PLATE, pneumatic valve 1
306† O-RING 2
307 CAP 2
308† U-CUP 2
309† SCREW 2
310 SNAP RING 2
311 DETENT SPRING 1
312 CUP 1
