Technical Data
3A3948B 47
Technical Data
Python XL Chemical Injection Pump
US Metric
Maximum pneumatic inlet pressure See Models on page 3.
Maximum fluid working pressure See Models on page 3.
Maximum cycle rate 100 cpm
Environmental temperature range -40°–176°F -40°–80°C
Noise (dBa)
Maximum sound pressure
<70 dBa with included muffler installed.
Inlet/Outlet Sizes
Fluid inlet size 1/4 in. npt(f)
Fluid outlet size (3/8”, 1/2”, 5/8”, & 3/4” plung-
ers only)
1/4 in. npt(f)
Fluid outlet size (1/4” plungers only) HiP HF4
Prime/bleed size (3/8”, 1/2”, 5/8”, & 3/4” plung-
ers only)
10-32 UNF
Prime/bleed size (1/4” plungers only) 1/16 in. npt(f)
Pneumatic inlet size 1/4 in. npt(f)
Exhaust fitting size 3/8 in. npt(f)
Materials of Construction
Pump/Check Valve Seal Material
See Configuration Chart on page 4 for seal material. All
other packing materials are PEEK and PTFE unless other-
wise noted.
Wetted Parts
See Configuration Chart on page 4 for plunger material. All
other materials are 316 stainless steel unless otherwise
noted.
Weight
All models 20.0 lbs. 9.1 kg
