Parts
3A3948B 35
Table 6: Inlet Valve Check (ref. 108)
Table 7: Outlet Valve Check (ref. 109)
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
108 B32226 B32024 B32024 B32024 B32024
1
FKMETP
108 B32228 B32026 B32026 B32026 B32026
1
HNBR
108 B32230 B32113 B32113 B32113 B32113
1
FFKM
108 B32232 B32028 B32028 B32028 B32028
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
109 B32227 B32025 B32025 B32025 B32025
1
FKMETP
109 B32229 B32027 B32027 B32027 B32027
1
HNBR
109 B32231 B32114 B32114 B32114 B32114
1
FFKM
109 B32233 B32029 B32029 B32029 B32029
1
