Graco Python XL 3/4" [38/48] Pneumatic motor parts
Parts
38 3A3948B
Pneumatic Motor Parts
Part No. B32251, 3.5 in. (88.9 mm), shown
Replacement Danger and Warning labels, tags, and cards are available at no cost.
† Included in Pneumatic Valve Seal Kit 24A535. See page 40.
Included in Pneumatic Valve Repair Kit 24A537. See page 40.
* Included in Pneumatic Motor Seal Kit 24G700.
Ref. Part Description Qty
201 24G696 Kit, cover, bottom (includes 202 (qty 1), 203, 207, 213 (qty 1), and 217) 1
202* Not sold separately. O-Ring, cover 2
203 Not sold separately. Bearing 1
204* Not sold separately. O-Ring, piston 1
205 15M211 Cylinder, motor 1
206 15M212 Cover, cylinder (includes English warning label) 1
229 15W719 Label, warning (French and Spanish) (not shown) 1
207* Not sold separately. Seal, u-cup 2
208* Not sold separately. Gasket, manifold 2
209*
† Not sold separately. Gasket, pneumatic valve 1
210 15X353 Kit, cover, top (includes 202 and 213 (qty 1 of each), and 230 and 231) 1
211 Not sold separately. Screw, M6 x 25 8
212
Bolt, tie, hex head 2
15M314 Bolt, tie, hex head 3
213 24A366 Valve, pilot (pack of 2) 1
214 24A351 Valve, pneumatic; includes items 209 and 211 (qty 4) 1
215 15M213 Muffler 1
217* Not sold separately. Ring, retaining 1
218 Not sold separately. Rod, pneumatic motor 1
219 24G698 Kit, piston, motor; includes 204 and 218, and 16G561 adhesive. 1
220 24A579 Manifold, assembly, includes 208, 209, and 211 (qty. 4) 1
230* Not sold separately. O-Ring, top plug 1
231 Not sold separately. Plug, top cover (ref. 210) 1
