Configuration Number Matrix
4 3A3948B
Configuration Number Matrix
Check the identification plate (ID) for the 12-digit Configuration Number of your pump. Use the following matrix to
define the components of your pump.
NOTE: Not all combinations are possible.
Sample Configuration Number: PCI-350-25S-XA-0
Pump Configuration
Key Points
• All pumps feature 1/4 in. NPT(F) inlet connections.
• Kit B32240 can be used to convert an HF4 outlet connection to a 1/4 in. NPT(F) for applications at or under
10,000 psi.
Lower Configuration
PCI 350 25 S X A 0
Pneumatic
Chemical
Injection
Pneumatic
Motor Size
Plunger Size Pressure Range Plunger Material Seal Material Qualifier
Pneumatic
Motor Size
Plunger Size
Outlet Connection
Type
Plunger Material
Seal
Material
Qualifier
350 3 1/2 inch 25 1/4” Diameter S 1/4” NPT(F) X Chromex A FKM 0 None
38 3/8” Diameter H HiP HF4 C Ceramic B FKMETP
50 1/2” Diameter C HNBR
63 5/8” Diameter DFFKM
75 3/4” Diameter
Plunger Size
Outlet Connection
Type
Plunger Material
Seal
Material
25 1/4” Diameter S 1/4” NPT(F) X Chromex A FKM
38 3/8” Diameter H HiP HF4 C Ceramic B FKMETP
50 1/2” Diameter
C HNBR
63 5/8” Diameter
DFFKM
75 3/4” Diameter
